Description
Features:
- Suitable for measuring dirty and wet compressed air, oxygen, natural gas and other industrial gases, steam, and etc.
- Wide measuring range, the low measuring limit can reach 1.5m/s.
- The turndown range ratio is 53:1, which exceeds the traditional vortex flow meters.
- Combining with DSA (digital full spectrum analysis technology), the flowmeter can accurately identify flow, vibration, and electromagnetic disturbance signals, greatly improving the anti-vibration ability of this vortex flow meter.
- Integrates pressure and temperature sensors to monitor online gas pressure and temperature.
- No moving parts, low pressure drop.
- Standard Modbus RTU (RS485) interface, 4 to 20 mA current and pulse output.
- Bluetooth function for wireless flowmeter configuration and data transmission.
- The fully welded structure has better corrosion and high pressure and temperature resistance.
- Explosion-proof class: Ex db IIC T6 Gb / Ex tb IIIC T80°C Db
- English, Spanish, French and other languages on request are available for LCD display.
- Each flow meter is calibrated and assigned a unique serial number corresponding to all calibration data.
Applications:
General
- Utility applications: Energy distribution in auxiliary and supply circuits
- Measurement of (non-)conductive liquids, gases, saturated and – superheated steam
- Gross/net heat metering of steam and hot water
- Measurement of consumption of industrial gases (natural gas, nitrogen etc.)
- Measurement of consumption in compressed air systems
Chemical and other process industries
- Hydrocarbons, thermal oils etc.
- Solvents
- Desalinated water
- Gases, welding gases, steam
- Petrochemical products (benzene, ethylene, etc.)
Iron, steel and metal industry
- Cooling circuits
- Compressed air
- Inert gases
- Oxygen
- Natural gas
- Steam
Food and beverage industry
- Purified and desalinated water
- CO2
- Burner consumption
- Steam
Pulp and paper industry
- Compressed air, steam etc.
Oil and gas industry
- Petrochemical products (benzene, ethylene, steam, etc.)
- Natural gas
